Vendor:LOBOO

Aluminum Panniers for Suzuki V-Strom 800DE with Top Case and Racks | CONQUEROR 105 L

Sale price€153,00Regular price €170,00
In stock, ready to ship

Up to 105 liters – nine-point attachment – same key for the whole set

JP421W — Cosa è compreso nel prezzo
  • If you order panniers:the pannier or panniers in the chosen configuration, with internal organizer, keys, and mounting hardware.
  • If you order racks:the selected rack with all screws for assembly without drilling on the V-Strom 800DE.
  • Panniers and racks are separate items:panniers alone cannot be mounted on the motorbike; the corresponding rack is needed. Please check your configuration before completing the order.
  • 🔒 Closed system:LOBOO panniers can only be attached to LOBOO racks. There are no adapters for other brands' supports.
  • Tracked shipping throughout Italy,with product inspection before dispatch.
  • 24-month legal guarantee of conformityfor the consumer, with the claim process handled by us.
  • Spedizione gratuitaoltre 100 € in Italia, oltre 250 € in Europa
  • Garanzia 24 mesigaranzia legale di conformità
  • Pagamento a ratedisponibile al checkout
  • Reso entro 14 giornidalla ricezione dell'ordine

Hai dubbi sulla compatibilità? Contattaci prima dell'acquisto →

Contattaci su WhatsApp

I recommend them to you!
Discover the excellence of Loboo accessories on Endurrad, designed to ensure maximum reliability on your two-wheeled adventures.

Original LOBOO product, guaranteed

105L

Total volume

16,57kg

Set of three suitcases

9

Attachment points

V-Strom 800DE

Motorcycle

System

Series

CONQUEROR

LOBOO aluminum suitcases

Total capacity

105

Set of three suitcases

Finishes

Silver · Black

C40T Top Case

Capacity

40

Measurements

416 × 379 × 363

Width × depth × height

Weight

5,59

Left C35L pannier

Capacity

35

Measurements

488 × 267 × 397

Length × depth × height

Weight

5,7

Right pannier C30R

Capacity

30

Shaped on the exhaust pipe

Measurements

488 × 243/207 × 397

Top and bottom depth

Weight

5,28

Construction

Material

High-strength aluminum alloy

Anodized surface

Hook

9 points, quick release

Patent ZL 2017 2 0624675.2

Lock

5-pin cylinder

Numbered keys

Waterproofing

Declared, without an IP rating

Rubber gaskets, rivets, and adhesive

Equipment

Sensor light

LR08

One for every suitcase: 30/60 lm, 600 mAh, IP66, headband

Internal

Pocket in the lid · flocked lining

Backrest

On the C40T top case

Load

Recommended by LOBOO

10 kg per side · 5 kg top case

For driving vibrations

Compatibility

Motorcycle

Suzuki V-Strom 800DE

Since 2024

Frames

JP421B · JP421W

Side panels and top case plate, sold as variants

Data from LOBOO official documentation.

Panniers, top case, and racks designed together for the V-Strom 800DE from 2024.

All you need to know before ordering

Technical specifications, equipment, delivery, and warranty: find every detail, verified against official LOBOO documentation, below.

Description Aluminum Panniers for Suzuki V-Strom 800DE with Top Case and Racks | CONQUEROR 105 L

The CONQUEROR aluminum luggage system for the Suzuki V-Strom 800DE from 2024: left C35L 35-liter case, right C30R 30-liter case, C40T 40-liter top case, plus the JP421B side racks and JP421W top case plate. 105 liters in total.

How the order is composed

On this page, choose the pieces you need, from a single component to the complete set. Cases and racks are separate items: the cases cannot be mounted on their own; the corresponding rack is required.

  • JP421B side racks for the two side cases: parts list and installation on the JP421B side racks page
  • JP421W top case plate for the top case: parts list and installation on the JP421W top case plate page
  • C35L + C30R side cases, in silver or black
  • C40T top case, in silver or black
  • Three-case set, in silver or black

Dimensions and weights declared by LOBOO

  • C40T top case: 416 × 379 × 363 mm, 5.59 kg, 40 liters
  • Left C35L: 488 × 267 × 397 mm, 5.7 kg, 35 liters
  • Right C30R: 488 × 243/207 × 397 mm, 5.28 kg, 30 liters

The right case is 243 mm deep at the top and 207 mm at the bottom: it is shaped to clear the exhaust. These measurements were taken manually, so there is some tolerance.

Nine-point attachment

The side cases attach to the rack at nine points, with quick release and a patented system. LOBOO states that they remain secure without vibrations even after prolonged use, stay attached in the event of a fall or slide, and detach in a frontal impact to reduce the risk of swerving.

Construction

  • High-strength aluminum alloy with an anodized surface
  • Technical plastic corner protectors and rubber bumpers on the outer corners of the side cases
  • Water resistance with rubber gaskets, rivets and adhesive, and a CNC-machined aluminum lid frame
  • Key lock with a five-lever cylinder, protected from water and dust; numbered keys
  • Aluminum hinges and handles, with a lid opening stop
  • Riveted structure: damaged components can be replaced individually
  • Aluminum bars on the lid for securing a tent or bags

The manufacturer does not publish an IP rating for the cases, so we do not indicate one.

Equipment

Each case has a storage bag in the lid and an LR08 sensor light: with the complete set, there are three lights. The top case also has a passenger backrest, and the inside has a flocked lining.

Load

Due to riding vibrations, LOBOO recommends not exceeding 10 kg per side case and 5 kg in the top case. With the cases mounted, the motorcycle is wider: adjust your riding accordingly.

Other cases on the same racks

The JP421B racks also support the PIKE TRACKER aluminum cases P35L + P30R, the WANDERER semi-rigid cases and the ALPS inflatable cases. LOBOO aluminum cases, on the other hand, can only be mounted on LOBOO racks.

Why choose it
  • Designed for the V-Strom 800DE:Panniers, frames, and mounting interface are conceived together, not adapted from another model.
  • The right one is narrower for the exhaust:30 liters instead of 35, so the bike doesn't become wider on one side only.
  • Nine attachment points:No play after a few thousand kilometers on dirt roads.
  • One key only:Top case and side cases use the same cylinder.
  • Can be purchased in parts:Start with the frames, add the panniers whenever you want.
Who is it recommended for

How to place your order:

  • Starting from scratch:Take JP421B and JP421W frames plus the three-case set. This is the complete 105-liter solution.
  • You already have the frames:Choose only the cases, side cases, or top case.
  • You want to travel light:The side frame with only the C35L and C30R pair covers 65 liters and leaves the tail free.

This is not the right choice if:You do challenging off-roading and want luggage that can withstand falls and be crushed, because aluminum doesn't. In that case, look at the semi-rigid WANDERER cases, which the same frames accept. And if you have the street V-Strom 800 instead of the DE, these frames do not fit.

Documents and manufacturer

Assembly and notes

  • The frames attach to the V-Strom 800DE's original anchor points, without drilling or cutting, using the included screws. The modification is reversible.
  • Respect the maximum load per side frame and per luggage rack indicated by Suzuki in the motorcycle's manual, and the vehicle's overall load capacity.
  • Re-check tightening after the first 100-200 km and periodically when used on unpaved roads.
  • The load must not cover the license plate and tail lights or extend beyond the limits of the Highway Code.
  • Check that the panniers are securely attached before every journey, by pulling them upwards.
Download files

How does it work, in detail?

Top case, side case set, or three cases

Top case, side case set, or three cases

LOBOO offers three sets: the top case with the top case plate, the pair of side cases with the frames, or all three cases with frames and plate.

On this page, you can configure them using the variants.

For the V-Strom 800DE from 2024, only on LOBOO frames

For the V-Strom 800DE from 2024, only on LOBOO frames

Side frames, top case plate, and set are indicated for the Suzuki V-Strom 800DE from 2024 onward.

Manufacturer's note: LOBOO aluminum cases can only be mounted on LOBOO frames and luggage racks, and the frames can be mounted without damaging the motorcycle.

Aluminum and safety latch

Aluminum and safety latch

CONQUEROR is LOBOO's series of high-strength aluminum alloy luggage with quick-release mounting.

Here you can see it in silver: C40T top case above, side cases below.

Dimensions and weights of the three suitcases

Dimensions and weights of the three suitcases

C40T top case: 416 × 379 × 363 mm, 5.59 kg. C35L left pannier: 488 × 267 × 397 mm, 5.7 kg. C30R right pannier: 488 mm long and 397 mm high, 243 mm deep at the top and 207 mm at the bottom, 5.28 kg.

LOBOO warns that manual measurements may vary slightly.

Patented nine-point attachment

Patented nine-point attachment

The case and frame connect at nine points. LOBOO claims there is no vibration even after prolonged use; in the event of a fall or slide, the case remains attached, while in a frontal collision it detaches to reduce the risk of swerving.

Utility model patent ZL 2017 2 0624675.2.

Technical plastic and rubber corner guards

Technical plastic and rubber corner guards

On the outer edges of the side cases, there is a wear-resistant rubber bumper that absorbs impacts and protects the frame and its contents.

The corner protector is made of high-strength engineering plastic: it provides more friction on the asphalt during a slide, and the wide chamfer leaves more clearance when cornering.

Impact-absorbing sheets

Impact-absorbing sheets

The cases are made of high-strength aluminum alloy sheet metal. LOBOO states that in an accident, they absorb more energy, protecting the motorcycle subframe and the contents.

Anodized surface

Anodized surface

The sheets are anodized, both in the silver and black finishes.

One bag in each lid

One bag in each lid

The lid has a storage bag secured with elastic straps to keep small items separate.

In the LOBOO photos, all three lids are open on the V-Strom 800DE.

Outer bag, inner bag, and lining

Outer bag, inner bag, and lining

The lid bag has external pockets for tools and documents and an internal compartment for gloves or rain gear.

The interior is lined with flocked fabric, which prevents the load from knocking against the shell.

Water-resistant

Water-resistant

LOBOO states that it is rainproof, with rubber seals, German rivets, and Swiss adhesive.

It does not publish an IP rating: for documents and electronics, an internal waterproof bag is still a good idea.

CNC-machined lid frame

CNC-machined lid frame

The lid hinge is a single frame made of CNC-machined aluminum alloy, on which the gasket operates.

Bars on the lid

Bars on the lid

On the side covers, there are aluminum bars with through-holes for securing a tent, a dry bag, or other cargo.

Load the luggage on top

Load the luggage on top

LOBOO photos show a WANDERER bag and a tent secured on top of the side case, with the top case mounted.

The weight counts toward the recommended 10 kg limit per side case.

Five-lever lock, numbered keys

Five-lever lock, numbered keys

The cylinder is made in Taiwan, protected against water and dust, with five internal pins to reduce the risk of picking.

The keys are numbered: write down the number; you’ll need it to request a replacement if you lose them.

Hinges, handles, and riveted frame

Hinges, handles, and riveted frame

Aluminum alloy hinge with a stop and aluminum handle.

The structure is riveted: a damaged component can be replaced on its own, without replacing the suitcase.

Passenger backrest

Passenger backrest

The top case has a large, soft backrest contoured to support the back and lumbar region.

The LR08 sensor light

The LR08 sensor light

Each suitcase has an LR08 light in the lid: it turns on automatically when it detects movement, is IP66-rated against water and dust, and has a strap for use as a headlamp.

With the complete set, there are three lights.

LR08 in numbers

LR08 in numbers

Up to 60 lumens, 600 mAh lithium-polymer battery (2.22 Wh), 32 g. The manual also specifies the low brightness setting of 30 lumens, USB-C charging at 5 V, and operation between −20 and +50 °C.

The fully equipped V-Strom 800DE

The fully equipped V-Strom 800DE

The official LOBOO photos show the V-Strom 800DE with the complete set, in silver and black, in three-quarter views.

Front, back, side

Front, back, side

From the side, front, and rear: this is how the motorcycle’s silhouette changes with the three cases.

LOBOO reminds you that the motorcycle is wider with the cases installed, and that you should adjust your speed accordingly.

FAQs

For more information, please see our FAQ.

Which motorcycles do they fit?

LOBOO declares the CONQUEROR system with the JP421B frames and JP421W plate for the Suzuki V-Strom 800DE from 2024 onward. The V-Strom 800, 800RE, and other V-Strom models are not listed: write to us with the model and year before ordering.

How many liters do they hold?

105 in total: 35 for the left case C35L, 30 for the right case C30R, 40 for the top case C40T.

Why is the suitcase on the right smaller?

Because the drain is on the right. The C30R is shaped to clear it: it is 243 mm deep at the top and 207 mm at the bottom, compared with 267 mm on the left.

How much do they weigh and how big are they?

C40T 416 × 379 × 363 mm and 5.59 kg; C35L 488 × 267 × 397 mm and 5.7 kg; C30R 488 × 243/207 × 397 mm and 5.28 kg. The three-case set weighs 16.57 kg empty, excluding frames.

Can suitcases be assembled without frames?

No. The side cases attach to the JP421B racks, and the top case to the JP421W mounting plate. On this page, you can order the racks, mounting plate, and cases together or separately.

How much weight can I load?

LOBOO recommends not exceeding 10 kg per side case and 5 kg in the top case due to riding vibrations. The motorcycle's maximum load specified by Suzuki still applies.

How does the nine-point hitch work?

The case attaches to the frame at nine points and is released using the safety button near the lock. LOBOO states that it remains securely in place without vibrations over time, stays attached in a fall, and detaches in a frontal impact.

Are they waterproof?

LOBOO states that it is rainproof, with rubber seals, rivets, adhesive, and a CNC-machined lid frame. It does not publish an IP rating, so we do not indicate one.

What type of lock do they have?

A five-pin cylinder protected against water and dust. The keys are numbered: note the number, as it is needed to request a new key if the key is lost.

What’s inside the suitcases?

Each case has the storage bag in the lid and an LR08 sensor light: with the complete set, there are three lights. The interior has flocked lining, and the top case has a backrest for the passenger.

What is the LR08 light like?

It turns on automatically with movement, has two brightness levels of 30 and 60 lumens, a 600 mAh battery rechargeable via USB-C, IP66 protection, and a headband for use as a headlamp. It weighs 32 g.

What happens if a suitcase is damaged?

The structure is riveted, and LOBOO states that damaged components can be replaced individually. Contact us with photos, and we’ll check which parts are available.

Can I mount other cases on the same frames?

Yes: the PIKE TRACKER P35L + P30R cases, the WANDERER soft cases, and the ALPS inflatable cases also fit the JP421B racks. The P45T, P36T, and T36T top cases also fit the JP421W plate.

How are they cleaned?

Water jet from at least one meter away, then use a soft brush or cloth with mild detergent. Do not use acidic or alkaline products, as they can damage the surface. Dry immediately with a cloth.

Didn't find the answer you were looking for?

Do not hesitate to contact us

Buying guides, technical comparisons, and news on adventure motorcycle accessories

Before choosing

View all

Triumph Tiger 900 Rally Pro attuale, vista frontale con paramani Barkbusters, parabrezza e faro anteriore

New Triumph Tiger 1200 and Tiger 900 2027: presentation dates, what is official and what to expect

Triumph unveils the Tiger 1200 on October 27 and showcases the Tiger 900 on December 15, 2026. What is official, what is merely speculation, and what to do with your Tiger’s accessories.

Read moreabout New Triumph Tiger 1200 and Tiger 900 2027: presentation dates, what is official and what to expect

Caricatore bidirezionale LOBOO C36 visto di tre quarti, display LED con tensione e indicatori SLA, LiON, IN, OUT

100 W USB-C charger for motorcycles: how much current it draws from the electrical system and what you can really connect

A 100 W USB-C socket draws at least 8.3 A from a 12 V system, and the 130 W LOBOO C36 draws at least 10.8 A. Charging profiles, 5 A cable, input mode, installation, and stated limits.

Read moreabout 100 W USB-C charger for motorcycles: how much current it draws from the electrical system and what you can really connect

Prototipo della KTM 990 Adventure in curva, vista di tre quarti anteriore con faro e cupolino

KTM 990 Adventure: what is really known, what EICMA 2026 will reveal, and what to do if you have a 790 or 890 Adventure

The KTM 990 Adventure is not official: KTM has only confirmed its presentation at EICMA 2026 on November 3. What is known, what is not, and what to do if you have a 790 or 890 Adventure.

Read moreabout KTM 990 Adventure: what is really known, what EICMA 2026 will reveal, and what to do if you have a 790 or 890 Adventure

Let customers speak for us

from 1125 reviews

Excellent quality
Good price
Very fast shipping and very well managed

Lea Rosset
6L Waterproof Crash Bar Bags
Waterproof Crash Bar Bags 6L
Premium upgrade on my BMW GS

I installed the JADO S6 on my BMW GS (non-"dedicated" version), and although I don't use the BMW base, the display and features are still top notch. The night visibility is impressive, and the "X-Ray" mode, as they call it, makes evening riding much safer. I also appreciate Endurrad's quick support for pre-purchase clarifications: fast shipping, careful packaging. A product that is really worth the expense for a premium upgrade.

Andrea
JADO S6 smart motorcycle driving system
JADO S6 smart motorcycle guidance system
Robust, complete, and perfect for long trips

As a motorcyclist who travels many miles, both on asphalt and off-road, I was looking for a solid display with advanced features: well, the JADO S6 exceeded my expectations. The body is sturdy, and the IP69K waterproof rating won me over from the very first downpour. The WiFi/BT connection is stable, and the dedicated app makes downloading dashcam videos super fast. All in one device, without having to mount 3-4 different accessories. Excellent value for money.

Filippo
JADO S6 smart motorcycle driving system
JADO S6 smart motorcycle driving system
The ultimate system for motorcycle travelers

Installed a few weeks ago on my adventure bike: the JADO S6 is truly a quantum leap in quality. The 6" screen is ultra-bright (even in direct sunlight it is perfectly visible) and the CarPlay/Android Auto interface works first time. The integrated dual dashcam gives me peace of mind on every trip. Installation was simple, with a clean fit without any invasive systems. Highly recommended for serious travelers who want a single smart control unit that does everything.

Giordi
JADO S6 smart motorcycle driving system
JADO S6 smart motorcycle guidance system
PROTECTION FOR MOTORCYCLE CRASH BARS

Excellent product, highly recommended. Be aware that it sells like hot cakes and is often out of stock... As soon as it's available, I'll buy more...

Eugenio
Protection for motorcycle crash bars - Endurrad
Protection for motorcycle crash bars - Endurrad

Bottle holder for motorcycle trips

Franco Della Porta
Bottle holder for motorcycle trips
Bottle holder for motorcycle trips
Great product, good value for money

The bag is of excellent quality and comes with all the necessary straps and a shoulder strap. The two methods of attaching it to the motorcycle are well designed and offer a range of options. I will also buy the larger model.

Andra Frois
Additional 20L Bag for Suitcases
20L Additional Bag for Suitcases

Excellent service

Manuele Mazzocato
Smart Protection for 12V Motorcycle Battery - Loboo CB20
Smart Protection for 12V Motorcycle Battery - Loboo CB20
Very satisfied

I saw the Endurrad ad on Facebook and immediately set about getting Loboo inflatable bags for my motorcycle...... But due to a technical error, I entered the wrong information on the order, which had already been shipped. Alarmed, I sent emails to the Endurrad staff, who, with their professionalism (and I must add, their patience), corrected the information both in the registration and with the courier, who was already on his way to deliver the order...Within two days, I received the bags and immediately tried them out and fitted them to my motorcycle. So I must say with great satisfaction that I was very pleased with the staff, with the product, and above all with the professionalism with which the marketing of all these products was carried out..... 🙂

Walter Fanale
Wanderer Inflatable Bags for Crash Bars - Endurrad
Wanderer Inflatable Bags for Crash Bars - Endurrad

CGRC CAN for AIO 5 Play BMW - Endurrad

Fabrizio Ghione
CGRC CAN for AIO 5 Play BMW - Endurrad
CGRC CAN for AIO 5 Play BMW - Endurrad
Excellent

Excellent product... Fast and punctual shipping. Giuseppe is knowledgeable, kind, and helpful.

CONTU ROBERTO
KOVE 800 X Side Cases - LOBOO PIKE TRACKER
KOVE 800 X Side Cases - LOBOO PIKE TRACKER
The most beautiful hand guards around

Materials, design, ease of assembly, height-adjustable spoiler, alloy core, all really beautiful and functional

Franco Pesci
Gloves for BMW GS: Protection and Comfort on Every Adventure
Handguards for BMW GS: Protection and Comfort in Every Adventure
Loboo L 11 spotlights

Very powerful light, very easy to install, even for someone like me who knows nothing about electrical systems.
Very happy

Franco Pesci
L11 15,000 Lumen Motorcycle Spotlights - Endurrad
L11 15,000 Lumen Motorcycle Spotlights - Endurrad
Untitled... just one thing: SERIOUS

I would say serious, honest, friendly professionals without controversy, because advertising is the basis of sales! As a motorcyclist, only excellent reviews!

Andrea Azzaroni
Wanderer Inflatable Bags for Crash Bars - Endurrad
Wanderer Inflatable Bags for Crash Bars - Endurrad
Loboo motorcycle bags

Reliability and professionalism...product as described...I was surprised by the quality of the details, starting with the box and everything else...top..top.....top

Carlo Di Domenico
6L Waterproof Crash Bar Bags
Waterproof Crash Bar Bags 6L
